Silver Cadmium Oxide Electrical Contact Rivets

Silver cadmium oxide electrical contact rivets, with their excellent arc erosion resistance and low contact resistance, are widely used in power switches, relays and other occasions to improve the stability and safety of electrical connections.

General Description

Alloy Material Inner Oxidized is widely used within method to make Oxidized Electrical,including AgSnO2, AgSnO2InO3, AgZnO2, AgCu0,AgCdO,etc. Alloy oxidation contact products are widely used in low-voltage electrical appliances

1,Inner Oxidized Electrical Contact owns excellent consistency ,tiny Oxidized material particle ,arc corrosion resistance and long electricity life .
2,Adding nickel and thulium to AgSnO2,AgSn02In2O3,AgZnO2,AgCuO,AgCdO,etc with the technology of low temperature high pressure oxidized takes effect on making grain tiny ,dispersion and aggrandizement ,consequently improves the mechanical strength ,ameliorate fusion ,arc corrosion resistance and abrasion.
3 ,Adopting melting pulverization and pre-oxidized manufacturing methods can make high quality contact material with the advantage of grain thin and organization uniformity ,no defection in microcosmic structure ,eliminating oxide leanness area.

Material Characteristics

Material	Specification(Wt%)						density ≥g/cm3	hardness HB ≥	resistance ratio ≤ μΩ.cm
Material	Ag	SnO2	In2O3	ZnO	CuO	CdO	density ≥g/cm3	hardness HB ≥	resistance ratio ≤ μΩ.cm
AgSnO2(8)	92.0	8.0	---	---	---	---	9.90	65	2.30
AgSnO2(10)	90.0	10.0	---	---	---	---	9.80	70	2.40
AgSnO2(12)	88.0	12.0	---	---	---	---	9.70	75	2.50
AgSnO2(5)In2O3(3)	92.0	5.0	3.0	---	---	---	9.90	70	3.20
AgSnO2(6)In2O3(4)	90.0	6.0	4.0	---	---	---	9.80	70	3.30
AgSnO2(7)In2O3(3)	90.0	7.0	3.0	---	---	---	9.80	75	3.30
AgSnO2(8)In2O3(4)	88.0	8.0	4.0	---	---	---	9.70	75	3.40
AgSnO2(9)In2O3(4)	87.0	9.0	4.0	---	---	---	9.60	80	3.50
AgSnO2(10)In2O3(4)	86.0	10.0	4.0	---	---	---	9.50	80	3.50
AgZnO(8)	92.0	---	---	8.0	---	---	9.70	65	3.20
AgZnO(10)	90.0	---	---	10.0	---	---	9.55	71	3.40
AgCdO(8)	92.0	---	---	---	---	8.0	10.05	64	2.00
AgCdO(10)	90.0	---	---	---	---	10.0	10.00	65	2.10
AgCdO(12)	88.0	---	---	---	---	12.0	9.90	67	2.30
AgCdO(13)	87.0	---	---	---	---	13.0	9.80	70	2.50
AgCdO(15)	85.0	---	---	---	---	15.0	9.75	70	2.70
AgCuO(10)	90.0	---	---	---	10.0	---	9.60	65	2.50

Customised Presentation of Results

From off-standard sizes and shaped structures to special performance requirements, customers around the globe offer deeply customised metal stampings and electrical connection components.

→

←
